AF/AS coatings, i.e., antifouling (AS) and anti-fingerprint (AF) films, are primarily used to deposit organic fluoride materials on various substrates, such as glass, organic glass (PC, PMMA, PET), using vacuum coating technology. This creates a surface with properties such as water resistance, oil resistance, scratch resistance, fingerprint resistance, stain resistance, and more.
Widely used in digital products, watches, hardware and other glass, metal, plastic, ceramic material panels, parts surface, and decorative and functional film plus AF, AS coating, improve surface hardness, smoothness, wear resistance, chemical resistance and easy cleaning.
Key Features of Impedance Evaporation AS Optical Coating Machine
Precision system of high precision optical multilayer film
Multiple component combinations to meet customer needs
Easy to operate and maintain
High performance, high throughput
Automatic evaporation control system to realize automatic evaporation process
Provide factory remote diagnostics
The range of initial contact angle is 115 ± 5 °
Friction resistance test standard of steel wool: use 0000 × 10 mm steel wool, area is 10 * 10 mm, travel 40 times / min, load 1kg, after 5000 times of back and forth friction, contact angle is greater than 100 °
Test standard of eraser: 6mm diameter eraser, 25 strokes / min, 1kg load, 2500 round-trip friction, contact angle greater than 100°
Note: the test sample glass shall be the touch screen cover plate special glass after precision polishing, with smooth surface.
| Mode | HCAF-1619 |
| Size | Φ1600x H1900mm |
| Structure | Vertical single door, All-In- One Box layout |
| Pumping speed | Atmospheric pressure to 2.0×10-3Pa≤30min |
| Ultimate vacuum | 8.0×10-5Pa |
| Jig Unit | Rotary shaft of the type of the planetary gear |
| Vacuum Unit | Low Vacuum Pump + High Vacuum Pump + Polycold |
| Vacuum Controller | Vacuum Controller, Penning Gauge, Pirani Gauge |
| Coating Unit | DC or MF Magnetron Sputtering Source + Plasma Source + Thermal Source |
| Charge Unit | MFC |
| Thickness Controller | Crystal Control |
| Controller | PLC+TP |
| Application | AF, Hard coating, Decorative coating, HR coating, etc. |
| Remark: Customization | |
Looking for a solution tailored to your needs? Our team is ready to provide you with expert guidance and support.
